ProSource
ProSource Y365CV-PS Storeroom Lever, Lever Handle, Stainless Steel, Commercial, 2 Grade, SC1 Keyway, 2-3/4 in Backset
- Backset Size: 2-3/4 in
- Backset Type: Fixed
- Bolt Throw Size: 1/2 in
- Color: Stainless Steel
- Commercial/Residential: Commercial
- Model #: Y365CV-PS
- UPC #: 045734656994
- SKU: 7534530
Your shopping list will be used for pickup in-store
Product Details
The ProSource Storeroom Cylindrical Lever suitable for use with 1-1/4 in - 1-13/16 in thick door. The seamless one-piece knob offers extra strength and it has an adjustable faceplate for flat or beveled door.Key Features
- Schlage SC1 six-pin keyway
- The door lever has Grade 2 ANSI
- Use for commercial or heavy-duty residential security
- The door lever is UL approved 3 hr fire rating
Item Specifications
| Backset Size | 2-3/4 in |
|---|---|
| Backset Type | Fixed |
| Bolt Throw Size | 1/2 in |
| Color | Stainless Steel |
| Commercial/Residential | Commercial |
| Cross Bore Diameter | 2-1/8 in |
| Cylinder Type | 6-Pin |
| Dimensions | 428 x 295 x 233 mm |
| Door Handing | Reversible |
| Door Thickness | 1-3/8 to 1-3/4 in |
| Edge Bore Diameter | 1 in |
| Faceplate Size | 1 x 2-1/4 in |
| Finish | Stainless Steel |
|---|---|
| Handle Type | Lever |
| Includes | (2) Keys |
| Key Type | Different |
| Keyway Type | SC1 |
| Latch Type | Fixed |
| Material | Stainless Steel |
| Number of Cylinders | 1 |
| Security Grade | 2 |
| Strike Size | 1-1/8 x 2-3/4 in |
| Strike Type | T-Style |
